Bafang 8fun BBS02B Conversion Ebike Kit 36V 500W Mid central motor kit with battery 36v 11.6Ah

OMAS CH955-67010 For DESIGNJET L25500 Optical Media Advance Sensor (OMAS) PCA BOARD plotter parts Free shipping POJAN For Videojet ink SIC board VB399054 for Videojet VJ1210 VJ1220 VJ1510 VJ1520 VJ1610 VJ1620 VJ1710 series NEW Original CQ109-67004 Q1273-60228 for HP Designjet 4000 4020 4500 4520 Z6100 T7100 L25500 42'' Belt Eco solvent printer Mutoh carriage scan motor for VJ1604 VJ1624 VJ1638 RJ900C RJ1300 RJ1304 RJ1204 DC Servo motor Y engine 1st NEW 0434B002 Scanner Exchange Roller Kit for Canon DR-5010C DR-6030C Inkjet printer spare parts DC servo motor Mutoh RJ900X/901X/1300C/1204E/1304 KP carriage scan motor 1pc retail CQ109-67005 Front Control Display Panel For Designjet z6200 PS CQ109 CQ111-60011 INK PRINTHEAD PLOTTER Main Board FREE SHIP Mutoh RJ900X DC servo motor KP MURJ900X for solvent printer 901X/1300C/1204E/1304 carriage scan motor 1pc 50 pieces 43.014.004 printing parts MO gripper machine cylinder seals,00.580.3371, spare parts Original New Maintenance Kit Q5998A Q5999A Q5422A Q5421A Q2436A Q2437A Q2430A Q2429A For HP 4345 M4345 4250 4350 4200 4300 Offset printing machine GTO52 Flanged bolt, 52.007.085/01,high quality,5 days shpping Toner refill powder compatible for OKI C310 color toner powder Original New Fuser Assembly RM1-5550 CE246A CC493-67911 RM1-5606 CE247A For HP CP4025 CP4525 CM4540 M651 M680 4525 4025 4540 651 High quality Akiyama gripper pad, Akiyama printing machines parts Original New Fuser Assembly RM1-2522 RM1-2524 RM1-2524-000CN RM1-3007 RM1-3008 For HP5200 M5025 M5035 HP 5025 5200 5035 Original New A4+ 8.5*14 inch ADF Assembly OEM#: CC476-67912 ADF whole unit assembly For HP M3027 M3035 HP3027 HP3035 Series New Printhead For HP 950 951 8100 8600 251DW 251 276 276DW 8610 8620 8630 8640 8660 8700 8615 8625 950XL 951XL CM751-80013A Single motor printer Take up System printer reel pickup system for all large format printer Original New For HP Z2100 HP Z3100 HP Z5200 Carriage Board PC board (PCA) OEM#: Q5669-60682 Q5669-20258 Original GL2 Card Formatter with HDD Memory Hard Drive Disk C7769-69143 C7769-69260 C7779-69272 C7769-60143 For HP 800 HP800 815 SEEBZ New Original M-4206 Thermal Printhead For Datamax M-Class M-4206 M-4208 M-4212,Barcord Printer Spare Parts,Warranty 90days Original New Carriage Assembly OEM#: Q1292-67040 C7791-60279 For HP130 HP130NR Series New Fuser Assembly Maintenance Kit F2G76A F2G77A F2G76-67901 F2G77F2G76-67901 For HP M60X M604 605 M606 604 605 606 Series FORMATTER PCA ASSY Formatter Board MainBoard mother card For HP T610 T1100 T1100PS Q6683-60193 Q6683-67023 Q6683-67030 100% Original printhead print head for Epson Stylus pro 7600/9600 printer ---- F138040/F138050 Original Printhead F138040 F138050 Print Head For Epson 7600 9600 2100 2200 Printer Head Original Fuser Assembly Fuser Kit Fuser Assy Fuser Unit 40X0648 40X0647 For LexMark W840 W842 W850 Series Original New Fuser Assembly Fuser Unit Fuser kit RG5-4319-000CN RG5-4319 RG5-4315 For HP8100 HP8150 HP 8100 8150 10pcs Brand New Self-tensioning Frame for Screen Printing Kit A Multi-Functional DIY Free Shipping FS7-0704-000 23T70T Fuser Feeder Drive Assembly Gear for Canon IR2200 IR2800 IR3300 Original Printhead F138040 F138050 Print Head For Epson Stylus Pro 7600 9600 Stylus Photo 2100 2200 Printer Head 10pcs 2HS25231 2HS25230 Upper Fuser Heat Roller for Kyocera FS1100 1110 FS1120 FS1300 FS1320 FS1028 FS1024 FS2000 KM2810 KM2820 for Epson R2400 Mainboard (Second Hand) Chip Permanent for Mimaki JV300 Cartridge 4 Colors CMYK printers New and Original Mutoh RJ-900C / VJ-1204 / VJ-1604 / VJ-1304 Panel Unit Assy printers for HP D5800 Bulk Ink System--4 Bottles(1300ml), 4 Cartridges with One-time Chip Tthermal Printhead for Mettler Toledo bCom bPro tiger 8442 3600 3660 3650 3680 3880 3950 3960 4610 4600 4880 6610 Print Head

Brand Name Ebird

Design Brushless

Voltage 36V

Wattage > 400w

Motor Type bafang mid drive motor kit

Name Bafang Motor Ebike Kit

Application Mountain Bike,City Bicycle,Snow Bike,Sand Bike

Model 36V/500W/KIT-BBS02-A

Packing Weight 6.4KG

LCD Display C965/850c/750c for your option

Chain Wheel At random

Feature Mid Drive

BB Size 68-73mm

Battery capacity 36v 11.6Ah

Charger included

[xlmodel]-[custom]-[39283] Spec Bafang 8fun BBS02B 36V 500W Brushless Mid Drive Crank Motor Conversion DIY Trike Ebike Kits Spec: 1. Voltage: 36V current Limit:25A 2. Power: 500W 3. Motor Weight: 4.2kgs 4. BB Length: 68mm-72mm 5. Working Temperature of Dsplay: - 20- 80. 6. Waterproof Grade: IP65 Installation: 1. Open the package and take out drive unit accessories; And check the specification whether it is correct. 2. Fix the chain wheel on drive unit with 5pcs screw M5*10, then fix chain cover on chain wheel with 5pcs screws ST3.9. 3. Fix the drive unit axle tube on frame bottom bracket. 4. The surface with teeth of fixing plate towards inside, then fix the plate on drive unit with 2pcs M6*10. 5. Hold the drive unit near to bicycle fork, force less than 5kgs, tight 1st nut M33 onto axle tube with force : 30-40N.m. 6. Fix 2nd nut M33 onto axle tube, tightening force: 30-40N.m. 7. Fix the left crank on the bike with M8 inner hexagon screw.Tightening force: 35-40N.m. 8. Fix the right crank on the bike with M8 inner hexagon screw.Tightening force: 35-40N.m. 9. Connect all cables for battery, display, speed detecting sensor and so on. 36V 11.6Ah lithium ion Down Tube electricbike battery pack with charger fit 250W 350W 500W bafang BBS01b motor 1.Ratedcapacity:11.6AH 2.Voltage:36V 3.ChargingVoltage:42V 4.Dischargecutoffvoltage:28V 5.Cell: 18650(10S5P) 6.Continuousdischargecurrent:20A 7.Pulse/Maxdischargecurrent60A 8.Maxchargingcurrent:5A 9.Diamesion:360*90*92mm(diameterXheigh) 84WLithiumIonChargerSpecification InputVoltage:100-240V OutputVoltage:42V(for10seriesLithiumIonbatteryuse) OutputCurrent:2A packing list 1 pcs 36V 11.6Ah Panasoniclithium ion battery pack 1 pcs 2A charger [xlmodel]-[photo]-[0000] Photos List [xlmodel]-[products]-[39084] Most Popular
